| Serial No | POWER | Vdc | Vrms | Irms(Amps) | Frequency | SPEED | DUTY CYCLE | COOLING |
|---|---|---|---|---|---|---|---|---|
| PMEC28 | 10.0 KW | 48 V | 3ϕ 31.4 V | 190 A | 60 | 80 Hz | 1760 | 2280 RPM | S2/ 5 min | IC 00 |
| PMEC29 | 15.0 KW | 72 V | 3ϕ 47.1 V | 190 A | 60 | 80 Hz | 1760 | 2280 RPM | S2/ 5 min | IC 00 |
| PMEC30 | 17.5 | 20 KW | 72 | 80 V | 3ϕ 41 | 45 V | 329 | 354 A | 58 | 60 Hz | 1656 | 1700 RPM | S2/ 5 min | IC 00 |
| PMEC52 | 11.5 KW | 48 V | 3ϕ 26 V | 336 A | 62 Hz | 1765 RPM | S2/ 5 min | IC 00 |
| PMEC57 | 3.0 KW | 24 V | 3ϕ 16.1 V | 150 A | 100 Hz | 2898 RPM | S2/ 5 min | IC 00 |
