| Serial No | POWER | Vdc | Idc(Amps) | SPEED | Field Excitation | DUTY CYCLE | COOLING |
|---|---|---|---|---|---|---|---|
| PMEC01 | 1.5 KW | 24 V | 90 A | 1800 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC02 | 1.7 KW | 30 V | 80 A | 1450 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC03 | 2.6 KW | 24 V | 36 V | 90 A | 1250 | 1450 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC04 | 3.6 KW | 36 V | 48 V | 110 A | 1250 | 1700 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC06 | 8.5 KW | 48 V | 190 A | 1450 RPM | SERIES | SEPEX | S2/ 1 HR | IC 01 |
| PMEC07 | 11.0 KW | 48 V | 270 A | 1450 RPM | SERIES | SEPEX | S2/ 1 HR | IC 01 |
| PMEC09 | 8.0 KW | 48 V | 175 A | 1250 RPM | SERIES | SEPEX | S2/ 1 HR | IC 01 |
| PMEC10 | 8.0 KW | 10.0 KW | 48 V | 72 V | 200 A | 1020 | 1500 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC34 | 4.0 KW | 36 V | 130 A | 2000 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00 |
| PMEC35 | 5.0 KW | 48 V | 130 A | 1500 RPM | SERIES | SEPEX | S2/ 1 HR | IC 00/01 |
